1. Product Overview
The wave ball system represents a revolutionary breakthrough in water park wave generation technology. Comprising an air compressor, storage tank, high-pressure lines, and a high-grade fiberglass sphere, the system forms a closed-loop pneumatic power network. By rhythmically driving the sphere up and down, it induces water resonance to generate natural, progressive waves. Unlike conventional massive pool-wide wave machines, the wave ball offers unparalleled flexibility with single or multi-ball configurations, eliminating the need for complex civil construction. Available in pneumatic and vacuum variants with smart PLC controls, it perfectly adapts to family resort pools, irregular water bodies, and leisure lagoons.
2. Product Specifications
| Parameter | Pneumatic wave ball Specifications | Vacuum wave ball Specifications |
| Model Number | WB-PL-2026L (Pneumatic Type) | WB-TS-2026M (Vacuum Type) |
| Application | Resort Pools, Family Leisure, Irregular Waters | High-Thrill Surf Zones & Premium Feature Areas |
| Wave Height | 0.3m – 1.2m (Adjustable) | Up to 4.0m Heavy Surf Experience |
| Wave Frequency | 10 – 30 Cycles / Minute | Smart Frequency Modulation via Effects |
| Single Ball Coverage | Approx. 80 sqm – 500 sqm (Expandable) | 300 sqm – 1,000+ sqm Enhanced Range |
| Minimum Water Depth | Requires Depth ≥ 1.2m | Requires Depth ≥ 1.8m |
| Sphere Diameter | 1.5m – 3.0m (Standard Options) | 2.5m – 4.0m (Custom Heavy-Duty Specs) |
| Installed Power | 45 kW – 110 kW | 130 kW – 300 kW+ |
| Control System | Smart PLC Control Cabinet with Touchscreen | Smart PLC Synchronized with AV Effects |
| Safety Features | Pressure Monitoring, Overpressure Relief, IP55, Emergency Stop | Pressure Monitoring, Overpressure Relief, IP55, Emergency Stop |
3. Key Features & Advantages
Innovative Modular Design Without Heavy Civil Works
Traditional wave pools demand massive excavation and complex concrete reservoirs. In contrast, the wave ball utilizes a streamlined modular architecture. It requires zero complex civil engineering and can be installed in existing irregular pools, hotel waters, or retrofit projects as a single unit or multi-ball array.
Premium Fiberglass & 316L Stainless Steel Framework
The sphere is built using high-grade fiberglass with an anti-aging gel coat finish for superior chemical and corrosion resistance. Larger models feature an internal 316L stainless steel framework with wall thicknesses of 8 to 12 millimeters, ensuring a lifespan exceeding 15 years in harsh outdoor pool environments.
Water Resonance Technology for Energy Efficiency
Pneumatic pressure drives the sphere to oscillate rhythmically, exciting water molecules to create smooth, progressive waves through resonance. The pneumatic wave ball offers exceptional energy efficiency, low operating noise, and steady performance, balancing guest thrills with low utility overheads.
Comprehensive Safety Monitoring & Control
Equipped with built-in pressure sensors, overpressure relief valves, and IP55 electrical enclosures. Shoreline emergency stop buttons and an intermittent operation mode ensure maximum equipment longevity and absolute swimmer safety.
4. Applications
- Retrofitting Irregular Pools, Hotel Waters, and Resort Leisure Lagoons
- Small-to-Medium Water Parks and Splash Pads Lacking Heavy Civil Infrastructure
- Secondary Wave Zones and Interactive Feature Points in Large Water Parks
